Flex Truck
1 / 5
| Project | Unit | Numeric Value |
|---|---|---|
| Large rated gross lifting capacity | kg | 25000 |
| The basic arm large lifting moment | kN.m | 1142 |
| Long main boom large lifting moment | kN.m | 768 |
| The basic arm large lifting height | m | 11.3 |
| The main boom max lifting height | m | 42.1 |
| The jib max lifting height | m | 50 |
| Single rope high speed (main winch) | m/min | 135 |
| Single rope high speed (sub-winch) | m/min | 120 |
| Boom boom time | s | 35 |
| Boom extension time | s | 80 |
| Rotation speed | r/min | 0~2.7 |
| Max travel speed | km/h | 90 |
| Gradeability | % | 45 |
| Small turning diameter | m | 21 |
| Fuel consumption per 100 km | L | 29 |
| Driving weight, total mass | kg | 33240 |
| Dimensions (L×W×H) | mm | 12870×2550×3520 |
| Outrigger lateral distance | m | 6.3 |
| Main arm length | m | 10.7~42 |
